TECHNICAL DATA - ACTIVE VERSION

WOOFER
• Number: 2
• Basket Ø: 7.5" (186 mm)
• Cone Material: HexaCone

MIDRANGE
• Number: 1
• Type: X-ART
• Velocity Transform Ratio: 3.5:1
• Diaphragm Weight: 0.7 g

TWEETER
• Number: 1
• Type:, X-ART
• Velocity Transform Ratio: 4:1
• Diaphragm Weight: 0.17 g

BUILT-IN AMPLIFIERS
• Woofer: 3
• Type: PWM
• Amp. Power RMS / Music: 200 W / 300 W
• Tweeter: 1
• Type: A/B
• Amp. Power RMS / Music: 50 W / 100 W

GENERAL DATA
• Frequency Response: 30 Hz - 50 kHz
• Crossover Frequencies: 150 / 800 / 2800 Hz
• Input Impedance: 10 kOhm
• Weight: 70.5 lb (32 kg)
• Height x Width x Depth: 47.5" (1205 mm) x 9" (230 mm) x 12" (300 mm)
• Finish: Black glossy, Cherry, Walnut
• Warranty: 5 years
• Delivery Contents: Front cover, spikes, plates, hex key, manual, power cord

TECHNICAL DATA - PASSIVE VERSION
WOOFER
• Number: 2
• Basket Ø: 7.5" (186 mm)
• Cone Material: HexaCone

MIDRANGE
• Number: 1
• Type: X-ART
• Velocity Transform Ratio: 3.5:1
• Diaphragm Weight: 0.7 g

TWEETER
• Number: 1
• Type: X-ART
• Velocity transform ratio: 4:1
• Diaphragm Weight: 0.17 g

GENERAL DATA
• Power Handling: 200 W / 300 W
• Efficiency: 90 dB / W / m
• Frequency Response: 33 Hz - 50 kHz
• Crossover Frequencies: 150 / 800 / 2800 Hz
• Impedance: 4 Ohm
• Weight: 70.5 lb (32 kg)
• Height x Width x Depth: 47.5" (1205 mm) x 9" (230 mm) x 12" (300 mm)
• Finish: Black glossy, Cherry, Walnut
• Warranty: 10 years
• Delivery Contents: Front cover, spikes, plates, hex key, manual, power cord (Active), Bi-wiring terminal (Passive)
