TECHNICAL PARAMETERS
• Nominal Impedance: 8 Ohm
• Minimum Impedance: 8.4 Ohm
• AES Power above 0.9 kHz (1): 80 W.
• AES Power above 0.65 kHz: 25 W
• Maximum Power above 0.9 kHz (2): 160 W
• Maximum Power above 0.65 kHz: 50 W
• Minimum Crossover Frequency (3): 0.9 kHz
• Sensitivity (1W/1m) (4): 110 dB
• Frequency Range: 0.7÷18 kHz
• Voice Coil Diameter: 65 mm (2.56 in)
• Winding Material: Al
• Former Material: Kapton
• Diaphragm Material: Ketone Polymer
• Diaphragm Shape: Dome
• Winding Depth: 2.1 mm (0.08 in)
• Magnetic Gap Depth: 4.2 mm (0.17 in)
• Flux Density: 1.8 T
• Magnet: Neodymium Ring
• Re: 6.7 Ohm
• Phase Plug Design: Annular
• Exit Angle (5): 29° Conical
• NET Air Volume filled by HF Driver: 0.4 dm^3 (0.014 ft^3)
