TECHNICAL PARAMETERS
• Nominal Impedance: 8 Ohm
• Minimum Impedance: 7.2 Ohm
• AES Power above 0.9 kHz (1): 100 W
• AES Power above 0.65 kHz: 50 W
• Maximum Power above 0.9 kHz (2): 200 W
• Maximum Power above 0.65 kHz: 100 W
• Minimum Crossover Frequency (3): 0.9 kHz
• Sensitivity (1W/1m) (4): 109 dB
• Frequency Range: 0.5÷18 kHz
• Voice Coil Diameter: 74 mm (2.91 in)
• Winding Material: Al
• Former Material: Kapton
• Diaphragm Material: Titanium
• Diaphragm Shape: Dome
• Winding Depth: 2.35 mm (0.09 in)
• Magnetic Gap Depth: 3.2 mm (0.13 in)
• Flux Density: 1.7 T
• Magnet: Ferrite Ring
• Re: 5.6 Ohm
• Phase Plug Design: Annular
• Exit Angle (5): 6° Conical
• NET Air Volume filled by HF Driver: 1.05 dm^3 (0.037 ft^3)
