1" - 30 W - 107 dB - 8 Ohms

• Nominal Impedance: 8 Ohm
• Minimum Impedance: 6.6 Ohm
• AES Power Handling (1): 30 W
• AES Power Handling (1): 60 W
• Maximum Power Handling (2): 2.6 kHz
• Minimum Crossover Frequency (3): 2.6 kHz
• Sensitivity (1W/1m) (4): 107 dB
• Frequency Range: 1.8÷20 kHz
• Voice Coil Diameter: Voice Coil Diameter: 25 mm (0.98 in)
• Winding Material: Al
• Former Material: Kapton
• Diaphragm Material: Ketone Polymer
• Diaphragm Shape: Dome
• Winding Depth: 1.7 mm (0.07 in)
• Magnetic Gap Depth: 2 mm (0.08 in)
• Flux Density: 1.3 T
• Magnet: Neodymium Ring
• Re: 6 Ohm
• Phase Plug Design: RadialExit
• Angle (5): 9° Conical
• NET Air Volume filled by HF Driver: 0.1 dm^3 (0.004 ft^3)
