A 16-channel digital mixer is a versatile audio device used for mixing and processing audio signals in various applications, such as live sound reinforcement, recording studios, and broadcasting.

• 12 Channel Mono Microphone / Line channel.
• 2 Stereo Circuit Channel.
• One SPIDFI Input / Output Channel.
• One AES / EBU Output Channel.
• Six customizable XLR Output ports.
• 9 Mixing Bus (4 AUX buses, 4 GROUP buses and 1 MAIN bus).
• 2 FX bus (effect sending bus).
• One 31-Segment GEQ (Equalizer).
• 1 Earphone monitor output port.
• 1 USB port, supporting U disk music playback.
• A 7 inch 1024x600 touch screen.
• 9 Electric moverswith 100mm stroke.
• 3 Shortcut mode call keys.
• 1 RS232 port, Support central control.
• Support bluetooth / USB playback, scene saving and call.

• LCD: 7.1 inch 1024x768
• Format Support: MP3, AAC, WAV, FLAC, APE
• Input Impedance: 3 k ohms
• Frequency Response: 20Hz - 20KHz (+/- 0.5dB)
• Max. Input Level: +15dBu (balanced input)
• S/N: -108dB
• THD: 0.005% (20Hz-20KHz) < 0.01% at 1K
• Power Supply: 24V (AC90 - 240V, 50/60Hz)
• Line Input: 4 Combo Carnons
• Input Impedance: 20K ohms
• XLR Output (Balanced): 8 Customized XLR outputs
• Recording Format: WAV

Digital Mixer 16-channel
DigiPro DGMX16
Professional Digital Mixer
Professional Audio Mixer
Digital Mixing Console
