Active Speaker - W440A

Model:	W440A
Manufacturer:	Montarbo \|Made in Italy

Discontinued

2-Way Active Bi-amplified speaker

Simplicity is the core of the project for this loudspeaker enclosure with its unique and innovative design. Flexible, rapid and safe assembling in fixed and mobile installations thanks to the 6 fly points included in the cabinet shape and to the very low weight. Ideal for use as main system for music performances, theatre, P.A, or as a stage monitor, W440A is an exceptionally accurate, highly versatile system, providing a rich and broad range of sound experiences in the most diverse situations.

FEATURES

High sound pressure levels without distortion.
Precise and detailed acoustic image. - 128 dB max SPL.
2 class-AB Mosfet amplifiers delivering a total output power of 400 W (LF 300 W, HF 100 W).
2 indipendent dedicated dynamic processors.
Active cross-over filter (24 dB/oct Linkwitz-Riley, 2500 Hz).
12" high efficiency woofer, with lightweight neodymium magnet assembly and 2.5" voice coil.
1" compression driver with 2" voice coil.
90° x 70° constant directivity horn.
Balanced input switchable to accept both line and microphone levels, enabling the W440A to be used as a stand-alone amplification system.
3-band equalizer. It allows to adjust the frequency response to the various applications, resulting in increased versatility.
Robust, lightweight and compact cabinet, made from HD polyethylene by rotational molding and equipped with two side handles for easy carry and set-up and with a stand adapter.
Unique and innovative design which includes 6 sturdy fly points (patented) completely integrated in the cabinet and designed to hang or angle the speaker in the air as required, using any type of hook available on the market.
The cabinet's shape allows for both vertical and horizontal installation (for use as stage monitor).
Ergonomically designed side handles for easy transportation and set-up.

TECHNICAL SPECIFICATIONS

ACOUSTIC DATA
Frequency Response [-3 dB]	45 Hz – 20 kHz
Max SPL	128 dB
HF	compression driver
HF Voice Coil	1”
HF Type	horn
Dispersion (HxV)	90 x 70
Crossover Frequency	2500 Hz
LF	12”
LF Voice Coil	2,5”
LF Type	reflex
AMPLIFIER
Amp Class	2 x AB MosFet 300W+100W
Peak Power	400 watt
RMS Power	280 watt
Self-rotating display	No
PROCESSOR
Controller	No
AD/DA Converter	No
System Presets	No
Limiter	Yes
Dual Active Peak, RMS, Thermal	Yes
INPUT SECTION
Signal input	XLR / Jack
Signal Out	XLR / Jack
USB Connector	No
MECHANIC
Flyable	Yes
Handles	Yes
Pole mount	Yes
Width	400 mm
Height	650 mm
Depth	355 mm
Weight	18,5 Kg

APPLICATIONS

Voice reinforcement system
Stage monitor
Theatrical sound reinforcement
Night clubs
Ballrooms
Conference centers, presentations
Houses of worship
Small to medium/large-sized main sound reinforcement systems
Fill-in and side-fills in larger PA systems.
