Active Speaker - PRX812

Active Speakers

Active Speaker - PRX812

Model: JBL PRX812
Manufacturer: JBL

JBL PRX812

JBL PRX812 12" Two-Way Full-Range Main System/Floor Monitor with Wi-Fi

Loudest-in-class Sound Reinforcement System with easy Wi-Fi Control

The JBL PRX812 is a full-range speaker designed for main system and floor monitor applications. Featuring a 12”, two-way, bass-reflex design powered by a 1500-watt class-D amplifier, PRX812 delivers incredible volume in a lightweight and compact form factor. It has been designed to deliver maximum performance for its weight and size as both a stage monitor and a front of house main PA. Two user selectable EQ settings are provided to optimize the system for either application. With a dual socket pole mount the PRX812 is a perfect match with a PRX818XLF subwoofer, offering a high performance self-powered sub/sat system. The PRX800 series integrates embedded ioSYS technology which enables easier setup and control when used with the HARMAN Connected PA app and compatible products. Connected PA delivers seamless plug-and-play operation with a variety of HARMAN equipment and enables you to control your entire live sound system with one app. Products within the Connected PA system self-identify and retain presets for effortless setup, and setup wizards help you quickly optimize speaker levels, configuration settings and EQ. Current products with embedded ioSYS technology and HARMAN Connected PA compatibility include the Ui24R mixer, JBL PRX800 loudspeakers, dbx Di1 direct boxes, and AKG P5i microphones and the MDAi dynamic microphone adapter.

• Built-in Wi-Fi
• Free PRX Connect mobile app for iOS and Android
• Class-leading 1500-watt amplifier

What's in the box?
• 1 x PRX812
• 1 x IEC Cable
• 1 x User's Guide

Built-in Wi-Fi
• For wireless control of your system from anywhere in the venue

• Free PRX Connect mobile app for iOS and Android

• Provides wireless control over volume levels, 8-band parametric EQ and up to 50ms of speaker delay to fine-tune your sound

• Class-leading 1500-watt amplifier
• Delivers ample power to fill your venue

• System Type: Self Powered 304mm, two-way, bass-reflex
• Maximum SPL Output: 135 dB peak
• Frequency Range (-10 dB): Main - 44.8 Hz – 20 kHz ; Monitor - 44.8 Hz – 20 kHz
• Frequency Response (±3 dB): Main - 55.7 Hz – 20 kHz ; Monitor - 56.5 Hz – 20 kHz
• Input Connectors: 2 x Balanced XLR / 6.35mm input, 2 x unbalanced RCA input
• Input Impedance: 20K Ohms (balanced), 10K Ohms (unbalanced)
• Signal Indicators: Limit - Yellow LED indicates peak output has been reached and dsp limiter is acting ; Signal - Green LED • • indicates signal present ; Power - Blue indicates system has power and ready to pass audio
• EQ: User selectable presets for Main or Monitor position, Advanced EQ settings available using Wi-Fi and PRX Connect application
• Dynamic Control (Input): dbx Type IV™ limiter circuit
• Crossover Frequency: 1.85 kHz
• Design: Highly efficient Class-D amplifier
• Power Rating: 1500W (750W x 2)
• AC Power Input: 100V - 240V ~ 50/60 Hz
• LF Driver: 1 x JBL 272G 305 mm woofer
• HF Driver: 1 x JBL 2408H-2 37.5 mm annular polymer diaphragm, neodymium compression driver
• Coverage Pattern: 90° x 50° nominal
• Directivity Index (DI): 10.2 dB
• Directivity Factor (Q): 10.4
• Enclosure: Asymmetrical, 18 mm, plywood
• Suspension / Mounting: Dual 36 mm pole socket, 12 x M10 Suspension Points
• Transport: 1 x injection molded handle with backing cup
• Grille: Powder coated, Obsidian, 16 gauge perforated steel with acoustical transparent black cloth backing
• Power Rating (W, Peak): 1500
• Frequency Response Hz (±3 dB): 56 - 20,000
• Maximum SPL (peak dB): 135
• Coverage Pattern (Nominal): 90° x 50°
• Country of origin: China

Dimensions:
• Height (mm)599.0
• Width (mm)385.0
• Depth (mm)341.0
• Weight (kg)18.1

JBL PRX812 12" Two-Way Full-Range Main System/Floor Monitor with Wi-Fi
