Active Speakers
Model: | Montarbo B108 Active Speaker |
Manufacturer: | Montarbo |Made in Italy |
Montarbo B108
Montarbo B108 Active Speaker |
B108 is a versatile, portable full-range active speaker suitable for small venue applications.
The bass-reflex cabinet is equipped with a 8” woofer and a 1”compression driver boosted by a 400 W amp module. Its advanced DSP featuring FIR filters allows a smooth audio performance as well as an impressive dimension/sound pressure level up to 125 dB.
B series speakers feature 3 input channels (Mic/line, Line, Bluetooth) with independent levels. Bluetooth devices can be easily connected thanks to the on-board “PAIR” button.
Moreover, 4 different on-board presets allows users to optimize the audio performance for the application in use.
A clean design integrates 3 handles, rigging points and a pole mount to the lightweight polypropylene cabinet which also allows horizontal stage monitor use, thanks to a 40° inclination of 2 sides of the box (a dedicated preset wedge EQ is selectable on board).
Covers for transport and weather protection are available as accessories for every model in Montarbo B series.
Features
• Active 2-way speaker
• Bluetooth stereo connectivity
• 3 channel INPUT
• Advanced DSP featuring FIR filters
• 4 on-board presets
• Up to 125 dB SPL
• Wedge use
• Pole mount
• Rigging points
Product Code: 1701000001
Acoustical Data
• Speaker Type: 2-way Active bass reflex
• Frequency Response [-10 dB]: 68 Hz - 20 kHz
• Max SPL: 125 dB
• HF: 1" driver
• LF: 8" - 2" VC
• Dispersion: 90° H x 60° V
• Crossover Frequency: 2.1 kHz
DSP
• Advanced Functions: FIR Filters
• DSP: 28/56 Bit
• AD/DA Converter: 24 bit, 48 kHz
• Controls: Ch. levels, MAIN level, PRESET button, Channel sens. LINK/MIX selection
• Connectors: CH1: Combo CH2: XLR-F + jack 6,35mm (1/4”) AUX IN: mini-jack 3,5mm LINE OUT: XLR-M
• Bluetooth ®>: 5.0 stereo
Amplifier
• Amp Class: D + A/B
• RMS Power: 200 W
• Peak power: 400 W
• Cooling: Convection
Enclosure
• Dimensions: 250 x 430 x 237 mm (9.8” x 16.9” x 9.3”)
• Weight: 8.5 kg (18.74 lb)
• Cabinet: Polypropilene
