Active Speaker - WIND PRO 212A

Active Speakers

Active Speaker - WIND PRO 212A

Model: WIND PRO 212A
Manufacturer: Montarbo |Made in Italy

Active Acoustic Loudspeaker

Montarbo Wind Pro 212A

Active Acoustic Loudspeaker

Montarbo® WIND PRO 212A is an active acoustic loudspeaker designed to guarantee extremely high performances in terms of power and quality.

The “Quasi 3-Way” acoustic design, combined with a sophisticated audio signal processing system, defines the new point-source standard, result of a 1.4” high-frequency coaxially horn-loaded driver with a 12 transducer with 3” voice coil, and an additional 12” woofer with 3” voice coil.

Montarbo® WIND PRO 212A is an designed to guarantee extremely high performances in terms of power and quality.

The “Quasi 3-Way” acoustic design, combined with a sophisticated audio signal processing system, defines the new point-source standard, result of a 1.4” high-frequency coaxially horn-loaded driver with a 12 transducer with 3” voice coil, and an additional 12” woofer with 3” voice coil.

• Very high performance-to-size ratio
• 2-channel amplifier 1200 W + 1200 W RMS
• 139 dB SPL
• Quasi 3-Way acoustic design
• 12” neodimium coaxial speaker with 3” voice coil and 1,4” Driver with 2,4” voice coil
• 12” ferrite woofer with 3” voice coil
• 70° horizontal, 50° vertical coverage
• 24 Bit 96 kHz DSP with M-Modelling Technology
• Integrated DANTE
• M-Modelling Technology
• Compatible Softwares: M-Connect and M-Simulation
• Wi-Fi Connection
• M-ID authentication system via app
• Integrated Rigging

ACOUSTIC DATA
• Frequency Response [-6dB]: 60 Hz - 18 kHz
• Max SPL: 139 dB
• COAX HF: 1.4"
• COAX HF Voice Coil: 2.4"
• COAX HF Type: Driver
• COAX LF: 12" Neo
• COAX LF Voice Coil: 3"
• Dispersion (H x V): 70º - 50º
• Auxiliary LF: 12" Ferrite
• Auxiliary LF Voice Coil: 3"
• LF Type: Reflex

AMPLIFIER
• Amp Class: 2 x class D 1200W LF + 1200W LMF - HF
• Peak Power: 3200 watt
• RMS Power: 2400 watt

PROCESSOR
• AD/DA Converter: Yes
• System Presets: Yes 4 Factory, 4 Users
• Limiter: Yes
• Dual Active Peak, RMS, Thermal: Yes

INPUT SECTION
• Signal Input: 2 x XLR Analog + Dante
• Signal Out: 1 x XLR
• Ethercon Connector: Yes

HARDWARE
• Housing: Plywood
• Flyable: Yes
• Handles: Yes
• Pole mount: Yes
• Dimension: 384 x 731 x 433 mm (15.1" x 28.8" x 17.0")
• Weight: 38.30 Kg (84.43 lb)

APPLICATIONS
• Theater
• Conferences
• Touring
• Rental
• Audio for System Integration
